table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:8.00pt "Arial", sans-serif; } .font3 { font:11.00pt "Arial", sans-serif; } .font4 { font:13.00pt "Arial", sans-serif; } Signal lamps Lens colour suitability for illumination Lens color transparent Suitable for: Lens colour opaque Suitable for: Filament lamps Neon lamps Filament lamps Neon lamps colourless limited good white limited not suitable red good good red good not suitable yellow good good yellow good not suitable green good limited* green limited not suitable blue limited limited* blue limited not suitable *Neon glow lamps are well suitable Neon lamps Neon lamps may glow on a short time after having been To avoid this, a parallel resistor with 1,2 MQ 1/4 W, can be switched off, for example in combination with long wires. used. Engraving and Hot Stamping Custom-made legend inserts, photographic film inserts or type setting A or narrow-spaced semi-bold type E, how-customer-specific inserts. Standard font DIN 30 640, thin ever, with rounded ends of characters. Type size* in mm Line thickness in mm Standard colour combinations Lens colour Legend 3 0,35 transparent: 4 0,5 colourless and red yellow, green, blue white white 5 0,6 6 0,7 opaque: 8 0,8 black and dark grey white, red, yellow, green blue and light grey white black black 10 1 12,5 1,2 *The selected type size depends on text length and lens size. Signal lamps 3 - 3
