Signal lamps with integrated lamp

Signal lamps with integrated filament/neon lamp, 10 mm

Electrical characteristics Voltage limit max.see order block Power limit max.see order block Other specifications Operating life10000 hDegree of protectionfrom front sideIP40 Weight2.5 g Approvals neon lamp (T=°C)VDE (85) at 1.5 W, VDE(120) at 1.6 mA
Panel cut-outPict.: blue

Technical data

General information Mechanical design Form of lenssee order block Colour of lenssee order block Diameter of collarsee order block Dimensions Mountingpressing into holeTerminalsquick connector 2.8 x 0.8 tin-platedLamp socketno Lampsee order block Length of collarsee order block Width of collarsee order block Overall height1.2 mm Mounting depth32 mm Mounting hole10 mm

3

Integr.Lamp

3 - 26Signal lamps

Stock items are markedby bold printed order numbers.
