Signal lamps with integrated lamp
Signal lamps with integrated filament/neon lamp, 7 mm
Electrical characteristics Voltage limit max.see order block
Power limit max.see order block Other specifications Operating life25000 hDegree of protectionfrom front sideIP40
Weight0.87 g
Approvals neon lamp
versionsVDE T85°,SEV T85°,FEMKO T85°b. 0.5 mA
Mounting holePict.: yellow Technical data
General information Form of lensround
Colour of lenssee order block
Diameter of collar8.5 mm Dimensions Overall height5 mm
Mounting depthsee order block
Mounting hole7 mm Mechanical design Mountingpressing into hole
Terminalssee order block
Lamp socketnoLampsee order block
3
Integr.Lamp 3 - 24Signal lamps
Stock items are markedby bold printed order numbers.
