Signal lamps with integrated lamp

Signal lamps with integrated filament lamp, 5 mm, square lens

Pict.: colourlessMounting hole Voltage limit max. Power limit max. Lamp Operating life Colour of lens Order no. 24 V 0.45 W filament lamp 10000 h transparentcolourless 1.69.508.103/1002 24 V 0.45 W filament lamp 10000 h transparent red 1.69.508.103/1301 24 V 0.45 W filament lamp 10000 h transparent yellow 1.69.508.103/1402 24 V 0.45 W filament lamp 10000 h transparent green 1.69.508.103/1502 24 V 0.45 W filament lamp 10000 h transparent blue 1.69.508.103/1601
Technical data see page 3 - 22

3

Signal lamps with integrated filament lamp, 5 mm, triangular lens

Integr.Lamp Pict.: blueMounting hole Voltage limit max. Power limit max. Lamp Operating life Colour of lens Order no. 24 V 0.45 W filament lamp 10000 h transparentcolourless 1.69.508.133/1002 24 V 0.45 W filament lamp 10000 h transparent red 1.69.508.133/1301 24 V 0.45 W filament lamp 10000 h transparent yellow 1.69.508.133/1402 24 V 0.45 W filament lamp 10000 h transparent green 1.69.508.133/1502 24 V 0.45 W filament lamp 10000 h transparent blue 1.69.508.133/1601
Technical data see page 3 - 22

Signal lamps3 - 23

Stock items are markedby bold printed order numbers.
