Signal lamps with integrated LED
Signal lamps with integrated LED, 10 mm, round lens
Pict.: greenEinbauffung Integrated currencyresistor Protecting diode Operating
voltage U Forward current, I F Lamp Light
intensity Order no. B yes yes 24 - 28 V 15 - 20 mA LED red 200 mcd 1.69.525.255/1000 yes yes 24 - 28 V 15 - 20 mA LED red 200 mcd 1.69.525.255/1300 yes yes 24 - 28 V 13 - 18.5 mA LED green 1000 mcd 1.69.525.260/1000 yes yes 24 - 28 V 13 - 18.5 mA LED green 1000 mcd 1.69.525.260/1500 yes yes 24 - 28 V 13 - 18.5 mA LED yellow 200 mcd 1.69.525.265/1000 yes yes 24 - 28 V 13 - 18.5 mA LED yellow 200 mcd 1.69.525.265/1400 >
3
yes yes 24 - 28 V LED blue 300 mcd 1.69.525.266/1000 yes yes 24 - 28 V LED blue 300 mcd 1.69.525.266/1600 yes yes 24 - 28 V LED white 400 mcd 1.69.525.271/1000 >
Integr.LED yes no 24 - 28 V 15 - 20 mA LED red 200 mcd 1.69.525.205/1000 yes no 24 - 28 V 15 - 20 mA LED red 200 mcd 1.69.525.205/1300 yes no 24 - 28 V 13 - 18.5 mA LED green 1000 mcd 1.69.525.210/1000 yes no 24 - 28 V 13 - 18.5 mA LED green 1000 mcd 1.69.525.210/1500 yes no 24 - 28 V 13 - 18.5 mA LED yellow 200 mcd 1.69.525.215/1000 yes no 24 - 28 V 13 - 18.5 mA LED yellow 200 mcd 1.69.525.215/1400 yes no 24 - 28 V LED blue 300 mcd 1.69.525.216/1000 yes no 24 - 28 V LED blue 300 mcd 1.69.525.216/1600 yes no 24 - 28 V LED white 400 mcd 1.69.525.221/1000 >
Technical data see page 3 - 18 Other voltages on request. 3 - 20Signal lamps
Stock items are markedby bold printed order numbers.
