RAFIX 16
RAFIX 16 buzzer
Electrical characteristics Operating voltage DC24 V
Input currentsee order block Mechanical characteristics Robustness min.100 N Other specifications Degree of protection
from front sideIP65
Ambient temp. operating
min.-25 °C
Ambient temp. operating
max.+70 °C
Storage temperature min.-40 °C
Storage temperature max.+85 °CResistance to constantenvironmentaccording to IEC 600 68-2-3 and 2-30Resistance at variable
environmentaccording to IEC 600 68-2-14 and 2-33
Panel cut-out 2
Technical data
Mechanical design General information Mountingring nut Form of lensflat lens
Colour of lensopaque black
Form of collarsee order blockSoundsee order block Dimensions Acoustic characteristics
RAFIX16 Length of collarsee order block
Diameter of collarsee order block
Key grid25 x 25 mm
Width of collarsee order block
Overall height6.95 mm
Mounting depth30.5 mm
Mounting hole16.2 mm Sonic pressure, 1 m
distance min.see order block
Accessories RAFIX 16 buzzer
Description Photo Order no. Page Fixing spanner for hexagon nut 5.58.002.034/0000 2 - 75
For additional accessories, refer to the chapter „RAFIX 16 special accessories“. 2 - 48Control components
Stock items are markedby bold printed order numbers.
