Control Components 2 - 5 2 RAFIX 16 RAFIX 16 is a complete control component series for a mounting hole diameter of 16.2 mm. It enables you to design attractive control panels with a minimum of space requirements and at the same time sufficiently large actuating areas. Actuators – Mounting hole ø 16.2 mm to DIN EN 50 007 Contact blocks – Standard (for actuators with one-way operation) • with latching mechanism (latching switch) • without latching mechanism (momentary switch) – Universal (for actuators with two-way operation, e. g. selector switches) • without latching mechanism Contact material – Silver contacts for mains voltage – Gold contacts for electronic circuits Illumination - Wedge base lamp W 2 x 4.6 d Assembly – Single-handed cost-effectiv assembly method – Panel thickness 0.5 … 5 mm – Fixing with hexagon nut – Starting torque 1.2 Nm max. Shock-resistance according to IEC 600 68-2-27 – Shock amplitude: 50 g – Shock time: 11 ms – Shock type: half sinusoidal Environment conditions – Constant environment: acc. to IEC 600 68-2-3 and 2-30 – Variable environment: acc. to IEC 600 68-2-14 and 2-33 Temperature range – Operating temperature: non-illuminated: - 25 … + 70 ° C illuminated: - 25 … + 55° C – Storage temperature: - 40 … + 85° C General information – Locating lug (easily removable). The locating lug can be easily removed using a screwdriver. – Degree of protection IP 65 on panel. This is achieved by a reliable, tried and tested special seal. – Grid spacing 25 x 25 mm – Low-profile design, 7 mm height from front panel – Three collar shapes, in black • Square 25 x 25 mm • Round 25 mm • Square 25 x 25 mm, alignable in flush fitting rows, which avoids accumulation of dirt between the collars. RAFIX 16
