2 - 44 Control components
2
RAFIX
16
RAFIX 16
RAFIX 16 potentiometer drive
Pict.: with potentiometer (not included) Einbauöffung
Technical data
General information
Form of lens handle
Colour of handle black
Form of collar see order block
Dimensions
Length of collar see order block
Diameter of collar see order block
Key grid 25 x 25 mm
Width of collar see order block
Overall height 23.65 mm
Mounting depth 19.2 mm
Mounting hole 16.2 mm
Mechanical design
Mounting ring nut
Other specifications
Degree of protection
from front side IP65
Ambient temp. operating
min. -25 °C
Ambient temp. operating
max. +70 °C
Storage temperature min. -40 °C
Storage temperature max. +85 °C
Resistance to constant
environment IEC 600 68-2-3 and 2-30
Resistance at variable
environment IEC 600 68-2-14 and 2-33
Description Photo Order no. Page
Accessories Potentiometer drive
Label holder, flush, for square collar 5.07.620.004/0000 2 - 76
Fixing spanner for hexagon nut 5.58.002.034/0000 2 - 75
For additional accessories, refer to the chapter „RAFIX 16 special accessories“.
