RAFIX 16
Mechanical characteristics Robustness min.100 N
Other specifications Degree of protection
from front sideIP65Ambient temp. operatingmin.-25 °C
Ambient temp. operating
without lamp max.+70 °C
Ambient temp. operating
with lamp max.+55 °C
Storage temperature min.-40 °C
Storage temperature max.+85 °C
Resistance to constant
environmentaccording to IEC 600 68-2-3 and 2-30Resistance at variableenvironmentaccording to IEC 600 68-2-14 and 2-33Operating life
(operations)300000
Panel cut-outPict.: red 2
Mechanical design
Technical data
Mountingring nut
Contact functionlatching
Contact arrangementaccording to contact block
Illuminabilityno General information Form of lenstoggle
Colour of toggle see order block
Form of collarsee order block Dimensions Length of collarsee order block
Diameter of collarsee order block
Key grid25 x 25 mm
Width of collarsee order block
Overall height18.4 mm
Mounting depth44.7 mm
Mounting hole16.2 mm
RAFIX16 Accessories RAFIX 16 toggle switch
Description Photo Order no. Page RAFIX 16 standard contact block, 1 NC + 1 NO, momentary, silver contacts, without lamp socket 1.20.122.021/0000 2 - 64 RAFIX 16 standard contact block, 1 NC + 1 NO, momentary, gold contacts, without lamp socket 1.20.122.031/0000 2 - 60 Label holder, flush, for square collar 5.07.620.004/0000 2 - 76 Fixing spanner for hexagon nut 5.58.002.034/0000 2 - 75
For other contact blocks, refer to the chapter „RAFIX 16 contact blocks“; for additional accessories, refer to the chapter „RAFIX 16 spe-cial accessories“. 2 - 40Control components
