Other specifications Operating life30000
Degree of protection
from front sideIP65
Ambient temp. operating
min.-25 °CAmbient temp. operatingwithout lamp max.+70 °C
Ambient temp. operating
with lamp max.+55 °C
Storage temperature min.-40 °C
Storage temperature max.+85 °C
Resistance to constant
environmentaccording to IEC 600 68-2-3 and 2-30Resistance at variableenvironmentaccording to IEC 600 68-2-14 and 2-33Corresponding to CE
Ma-Dir. 89/392yes
ApprovalsIEC 60204, IEC 73
RAFIX 16
panel cut-out 2
Mechanical design Mechanical characteristics
Technical data
Mountingring nut
Contact functionlatching
Contact arrangementaccording to contact block
Illuminabilitysee order block Robustness min.100 N
Robustnessacc. IEC 60947-5-5 General information Form of buttonsee order block
Colour of buttonsee order block
Form of collarsee order block Dimensions Length of collarsee order block
Diameter of collarsee order block
Key grid25 x 25 mm
Width of collarsee order block
Overall heightsee order block
Mounting depth44.7 mm
Mounting hole16.2 mm
RAFIX16 Accessories RAFIX 16 emergency stop pushbutton
Description Photo Order no. Page RAFIX 16 universal contact block, 1 NC, momentary, silver contacts, without lamp socket 1.20.123.022/0000 2 - 65 RAFIX 16 universal contact block, 1 NC, momentary, gold contacts, without lamp socket 1.20.123.032/0000 2 - 61 Fixing spanner for hexagon nut 5.58.002.034/0000 2 - 75 Emergency stop label, yellow, round 60 mm, PVC adhesive, without legend 5.76.204.400/0400 2 - 77
For suitable LEDs, filament lamps and other contact blocks, refer to the chapter „RAFIX 16 contact blocks“; for additional accessories,refer to the chapter „RAFIX 16 special accessories“. 2 - 34Control components
Stock items are markedby bold printed order numbers.
