RAFIX 16

RAFIX 16 keylock switch, RONIS, square collar, alignable without gaps

Panel cut-out Contact function Rotating angle Key removal position Order no. complete momentary 1 x 40° 1.30.176.541/0000 momentary 2 x 40° 1.30.176.741/0000 latching L, 1 x 90° 1.30.176.041/0000

2

latching L, 1 x 90° 0+1 1.30.176.091/0000
RAFIX16 latching V, 1 x 90° 1.30.176.141/0000 latching V, 1 x 90° 0+1 1.30.176.191/0000 latching 2 x 90° 1.30.176.341/0000 latching 2 x 90° 0+1+2 1.30.176.441/0000
Technical data see page 2 - 26 Only use contact blocks with "momentary" contact function. For versions with clockwise and counterclockwise rotation, use universalcontact block only. Included: 2 keys.

Control components2 - 29

Stock items are markedby bold printed order numbers.
