Stock items are marked by bold printed order numbers. RAFIX 16 2 - 16 Control components 2 RAFIX 16 RAFIX 16 pushbutton, flush lens, square collar, alignable without gaps Pict.: black panel cut-out Illuminability Colour of lens Order no. complete Order no. single parts Housing Lens yes transparent colourless 1.30.070.201/1002 1.30.070.701/0000 5.49.077.011/1002 yes transparent red 1.30.070.201/1306 1.30.070.701/0000 5.49.077.011/1306 yes transparent yellow 1.30.070.201/1403 1.30.070.701/0000 5.49.077.011/1403 yes transparent green 1.30.070.201/1505 1.30.070.701/0000 5.49.077.011/1505 yes transparent blue 1.30.070.201/1607 1.30.070.701/0000 5.49.077.011/1607 no opaque black 1.30.070.451/0100 1.30.070.951/0000 5.05.510.640/0100 no opaque white 1.30.070.451/0200 1.30.070.951/0000 5.05.510.640/0200 no opaque red 1.30.070.451/0300 1.30.070.951/0000 5.05.510.640/0300 no opaque yellow 1.30.070.451/0400 1.30.070.951/0000 5.05.510.640/0400 no opaque green 1.30.070.451/0500 1.30.070.951/0000 5.05.510.640/0500 no opaque blue 1.30.070.451/0600 1.30.070.951/0000 5.05.510.640/0600 Technical data see page 2 - 8 For the „latching“ function, please use the standard contact block with „latching“ function. Legend insert, blank, use only for transparent lenses: 5.70.635.000/2000 Accessories:
