RAFIX 16

RAFIX 16 pushbutton, protruding collar, round collar

Pict.: redpanel cut-out Illuminability Colour of lens Order no. complete Order no. single parts Housing Lens yes transparent colourless 1.30.070.121/1002 1.30.070.621/0000 5.49.259.017/1002 yes transparent red 1.30.070.121/1306 1.30.070.621/0000 5.49.259.017/1306 yes transparent yellow 1.30.070.121/1403 1.30.070.621/0000 5.49.259.017/1403

2

yes transparent green 1.30.070.121/1505 1.30.070.621/0000 5.49.259.017/1505
RAFIX16 yes transparent blue 1.30.070.121/1607 1.30.070.621/0000 5.49.259.017/1607 no opaque black 1.30.070.371/0100 1.30.070.871/0000 5.05.510.641/0100 no opaque white 1.30.070.371/0200 1.30.070.871/0000 5.05.510.641/0200 no opaque red 1.30.070.371/0300 1.30.070.871/0000 5.05.510.641/0300 no opaque yellow 1.30.070.371/0400 1.30.070.871/0000 5.05.510.641/0400 no opaque green 1.30.070.371/0500 1.30.070.871/0000 5.05.510.641/0500 no opaque blue 1.30.070.371/0600 1.30.070.871/0000 5.05.510.641/0600
Technical data see page 2 - 8 The protruding collar offers protection against inadvertent operation and thereby fulfils the safety requirements of various machinerymanufacturers, particularly in the printing industry. For the "latching" function, please use the standard contact block with "latching" function.Legend insert, blank, use only for transparent industrial lenses: 5.70.637.000/2000 Accessories:

Control components2 - 15

Stock items are markedby bold printed order numbers.
