Pushbuttons 1 - 1 Page 1 General Information 1 - 2 8 mm Series 1 -3 8 mm Series, illuminated pushbutton, 42 V/250 mA 1 -4 8 mm Series, signal lamp 1 -6 LUMOTAST FK 1 -9 LUMOTAST FK illuminated pushbutton, 42 V/100 mA 1 -12 LUMOTAST FK signal lamp 1 -16 LUMOTAST 25 1 -19 LUMOTAST 25 illuminated pushbutton 1 -22 LUMOTAST 25 selector switch 1 -28 LUMOTAST 25 keylock switch 1 -30 LUMOTAST 25 emergency stop pushbutton 1 -32 LUMOTAST 25 signal lamp 1 -34 LUMOTAST 75 IP40 1 -37 LUMOTAST 75 illuminated pushbutton IP40 1 -38 LUMOTAST 75 keylock switch IP40 1 -44 LUMOTAST 75 IP40 signal lamp with lamp socket T 4.5 1 -48 LUMOTAST 75 IP65 1 -53 LUMOTAST 75 illuminated pushbutton IP65 1 -54 LUMOTAST 75 signal lamp IP65 1 -62 Other keylock switches 1 -67 Keylock switch 1 -68 Priority keylock switch 1 -72 Other pushbuttons 1 -75 Pushbutton opaque, mounting hole diameter 9.1 mm, non-illuminated, 24 V/100 mA 1 -76 Illuminable pushbutton, mounting hole diameter 9.1 mm, 24 V/0.5 A 1 -78 Pushbutton, opaque, mounting hole diameter 15.2 mm, 250 V/0.7 A 1 -80 Pushbutton, opaque, mounting hole diameter 16.2 mm, 250 V/2 A 1 -82 Pushbutton, opaque, mounting hole diameter 18.2 mm, 250 V/2 A 1 -84 Illuminable pushbutton, with lamp socket BA9s (MBC/MCC), mounting hole diameter 20.3 mm, 250 V/2 A 1 -86 VARIOTAST V11 main switch 1 -88 Pushbuttons
