8 mm Series
8 mm Series, signal lamp
Other specifications Degree of protection
from front sideIP40
Weight2 Ambient temp. operating
min.-25 °CAmbient temp. operatingmax.+55 °C
Storage temperature min.-40 °C
Storage temperature max.+80 °C
Resistance to constant
environmentaccording to IEC 600 68-2-3 and 2-30Resistance at variable
environmentaccording to IEC 600 68-2-14 and 2-33Soldering time max.3 sec.
Soldering temperature
max.350 °C
1
8 mm Mounting hole Technical data
Mechanical design General information Mountingring nutTerminalssolder terminals, tin-platedLamp socketBi-Pin T 1
Lampfilament lamp / LED Form of lensprotruding lens
Colour of lenssee order block
Form of collarsee order block Dimensions Length of collar8.9 mm
Width of collar8.9 mm
Diameter of collarsee order block
Overall height9 mm
Mounting depth31 mm
Mounting hole8.1 mm Electrical characteristics Voltage limit max.24 V
Power limit max.0.4 W
Accessories 8 mm Series, signal lamp
Description Photo Order no. Page Filament lamp, Bi-Pin T 1 base, 24 - 28 V 1.90.180.473/0000 5 - 5 LED Bi-Pin T 1, red, 3 V 1.90.691.026/0000 5 - 17 LED Bi-Pin T 1, green, 3 V 1.90.691.027/0000 5 - 17 LED Bi-Pin T 1, yellow, 3 V 1.90.691.028/0000 5 - 17 Fixing spanner M 8 5.58.002.027/7705 5 - 25
1 - 6Pushbuttons
Stock items are markedby bold printed order numbers.
