Text version of the page
Stock items are marked
by bold printed order numbers.
Pushbuttons 1 - 5
1
8 mm
8 mm Series
Description Photo Order no. Page
Accessories 8 mm Series, illuminated pushbutton, 42 V/250 mA
LED Bi-Pin T 1, yellow, 3 V 1.90.691.028/0000 5 - 17
Fixing spanner M 8 5.58.002.027/7705 5 - 25
8 mm Series, illuminated pushbutton, round collar, 42 V/250 mA
Pict.: with colourless lens Mounting hole
Contact arrangement Contact function Lamp socket Order no.
without lens
Note
1 NO momentary Bi-Pin T 1 1.15.116.001/0000 Please include the desired lens in
your order.
1 NO latching Bi-Pin T 1 1.15.116.011/0000 Please include the desired lens in
your order.
Technical data see page 1 - 4
Lens, transparent colourless: 5.05.510.470/1002
Lens, transparent red: 5.05.510.470/1303
Lens, transparent yellow: 5.05.510.470/1402
Lens, transparent green: 5.05.510.470/1502
8 mm Series, illuminated pushbutton, square collar, 42 V/250 mA
Pict.: with green lens Mounting hole
Contact arrangement Contact function Lamp socket Order no.
without lens
Note
1 NO momentary Bi-Pin T 1 1.15.116.021/0000 Please include the desired lens in
your order.
1 NO latching Bi-Pin T 1 1.15.116.031/0000 Please include the desired lens in
your order.
Technical data see page 1 - 4
Lens, transparent colourless: 5.05.510.471/1002
Lens, transparent red: 5.05.510.471/1303
Lens, transparent yellow: 5.05.510.471/1402
Lens, transparent green: 5.05.510.471/1502
