LUMOTAST 25
LUMOTAST 25 signal lamp, 24 V, „Click“ quick-assembly feature
1
Pict.: redPanel cut-out Voltage limit max. Power
limit max. Lamp socket Colour of lens Order no. complete Order no. single parts Housing Lens 24 V 0.7 W Bi-Pin T 1/T 1
1 /
4 transparentcolourless 1.65.122.006/1002 1.65.122.906/0000 5.49.077.014/1002 24 V 0.7 W Bi-Pin T 1/T 1
1 /
4 transparent red 1.65.122.006/1306 1.65.122.906/0000 5.49.077.014/1306
LUMO25 24 V 0.7 W Bi-Pin T 1/T 1
1 /
4 transparent yellow 1.65.122.006/1403 1.65.122.906/0000 5.49.077.014/1403 24 V 0.7 W Bi-Pin T 1/T 1
1 /
4 transparent green 1.65.122.006/1505 1.65.122.906/0000 5.49.077.014/1505 24 V 0.7 W Bi-Pin T 1/T 1
1 /
4 transparent blue 1.65.122.006/1607 1.65.122.906/0000 5.49.077.014/1607
Technical data see page 1 - 34 Accessories: Legend insert for illuminated versions:5.70.635.000/2000Do not press in lens in disassembled condition. Note when using a LED: A notch on the lamp identifies the cathode side.
Technical data see page 1 - 34 LUMOTAST 25 signal lamp, 24 V, ring nut fixing
Pict.: bluePanel cut-out Voltage limit max. Power
limit max. Lamp socket Colour of lens Order no. complete Order no. single parts Housing Lens 24 V 0.7 W Bi-Pin T 1/T 1
1 /
4 transparentcolourless 1.65.122.056/1002 1.65.122.956/0000 5.49.077.014/1002 24 V 0.7 W Bi-Pin T 1/T 1
1 /
4 transparent red 1.65.122.056/1306 1.65.122.956/0000 5.49.077.014/1306 24 V 0.7 W Bi-Pin T 1/T 1
1 /
4 transparent yellow 1.65.122.056/1403 1.65.122.956/0000 5.49.077.014/1403 24 V 0.7 W Bi-Pin T 1/T 1
1 /
4 transparent green 1.65.122.056/1505 1.65.122.956/0000 5.49.077.014/1505 24 V 0.7 W Bi-Pin T 1/T 1
1 /
4 transparent blue 1.65.122.056/1607 1.65.122.956/0000 5.49.077.014/1607
Accessories: Legend insert for illuminated versions:5.70.635.000/2000Do not press in lens in disassembled condition. Note when using LED: A notch on the lamp socket identifies the cathode side. 1 - 36Pushbuttons
Stock items are markedby bold printed order numbers.
