LUMOTAST 25
LUMOTAST 25 signal lamp
1
Panel cut-outPict.: red Mechanical design
Technical data
LUMO25 Mountingsee order block
Terminalspin connector 4-pol./ plug-in socketLamp socketBi-Pin T 1/T 1 General information Electrical characteristics Form of lenssquare
Colour of lenssee order block Voltage limit max.24 V
Power limit max.0,7 W Dimensions Other specifications Length of collar25 mm
Width of collar25 mm
Overall height9.8 mm
Mounting depth with
connector30.7 mm
Mounting depth with
plug-in socket33.4 mm
Mounting hole16.2 mm Degree of protectionfrom front sideIP65
Weight7 g
Ambient temp. operating
min.-25 °C
Ambient temp. operating
max.+70 °C
Storage temperature min.-40 °C
Storage temperature max.+80 °C
1 /
4 Lampfilament lamp/LED
Accessories LUMOTAST 25 signal lamp
Description Photo Order no. Page Filament lamp, Bi-Pin T 1
1 /
4 base, 12 V 1.90.180.474/0000 5 - 5 Filament lamp, Bi-Pin T 1
1 /
4 base, 28 V 1.90.180.475/0000 5 - 5 LED Bi-Pin T 1 superbright, red, 24 V 1.90.690.351/0000 5 - 18 LED Bi-Pin T 1 superbright, green, 24 V 1.90.690.352/0000 5 - 18 LED Bi-Pin T 1 superbright, yellow, 24 V 1.90.690.353/0000 5 - 18 LED Bi-Pin T 1 superbright, blue, 24 V 1.90.690.354/0000 5 - 18 LED Bi-Pin T 1 superbright, white, 24 V 1.90.690.355/0000 5 - 18 LED Bi-Pin T 1, red, 3 V 1.90.691.026/0000 5 - 17
1 - 34Pushbuttons
Stock items are markedby bold printed order numbers.
