LUMOTAST 25
1
Electrical characteristics Rated voltage AC/DC max.42 V
Rated voltage AC/DC min.0.02 V
Rated current AC/DC max.100 mARated current AC/DC min.0.01 mAContact resistance max.100 m
Panel cut-outPict.: bluePict.: colourless Ω Bouncing time max.5 ms Other specifications Mechanical design Operating life
(operations)1000000
Degree of protection
from front sideIP65
Ambient temp. operatingwithout lamp min.-25 °CAmbient temp. operating
without lamp max.+70 °C
Ambient temp. operating
with lamp min.-25 °C
Ambient temp. operating
with lamp max.+55 °C
Storage temperature min.-40 °C
Storage temperature max.+80 °C
Resistance to constant
environment acc. to IEC 600 68-2-3 and2-30Resistance at variable
environment acc. to IEC 600 68-2-14 and2-33Weight7 g Mountingsee order block
Terminalspin connector 4-pol./ plug-in socketContact systemsnap-action contact
Contact functionmomentary
Contact arrangement1 NO Contact materialsAu
Illuminabilityyes
Lamp socketBi-Pin T 1/T 1
Technical data
LUMO25 General information Form of lenssee order block
Colour of lenssee order block
Form of collarsquare Dimensions Length of collar25 mm
Width of collar25 mm
Overall height7.1 mm
Mounting depth with
connector30.7 mm
Mounting depth with
plug-in socket33.4 mm
Mounting hole16.2 mm
1 /
4 Operating force max.6 N
Operating travel3 mm
Switching travel2 mm
Robustness min.100 N Mechanical characteristics
Accessories LUMOTAST 25 illuminated pushbutton
Description Photo Order no. Page Filament lamp, Bi-Pin T 1
1 /
4 base, 12 V 1.90.180.474/0000 5 - 5 Filament lamp, Bi-Pin T 1
1 /
4 base, 28 V 1.90.180.475/0000 5 - 5 LED Bi-Pin T 1 superbright, red, 24 V 1.90.690.351/0000 5 - 18
1 - 22Pushbuttons
