LUMOTAST FK
Accessories LUMOTAST FK signal lamp
Description Photo Order no. Page LED Bi-Pin T 1, red, 3 V 1.90.691.026/0000 5 - 17 LED Bi-Pin T 1, green, 3 V 1.90.691.027/0000 5 - 17 >
1
LED Bi-Pin T 1, yellow, 3 V 1.90.691.028/0000 5 - 17 Plug-in socket for PCB 5.00.645.036/0000 5 - 28 Cable (flat ribbon cable 10 cm with socket connector andmale quick connector, AMP 4-pin) 5.03.771.306/0000 5 - 27 >
LUMOFK Disassembly tool for LUMOTAST FK 5.05.800.041/0000 5 - 26 Flat ribbon cable, 4-wire, 1 m long 5.37.700.124/0000 5 - 27 Socket connector, 4-pin 5.92.025.368/0000 5 - 26 >
LUMOTAST FK signal lamp, square collar
Pict.: redPanel cut-out Powerlimit max. Voltage limit max. Lamp socket Colour of lens Order no. complete Order no. single parts Housing Lens 0.7 W 24 V Bi-Pin T 1/T 1 >
1 / >
4 transparentcolourless 1.65.121.006/1002 1.65.121.906/0000 5.49.075.015/1002 0.7 W 24 V Bi-Pin T 1/T 1 >
1 / >
4 transparent red 1.65.121.006/1306 1.65.121.906/0000 5.49.075.015/1306 0.7 W 24 V Bi-Pin T 1/T 1 >
1 / >
4 transparent yellow 1.65.121.006/1403 1.65.121.906/0000 5.49.075.015/1403 0.7 W 24 V Bi-Pin T 1/T 1 >
1 / >
4 transparent green 1.65.121.006/1505 1.65.121.906/0000 5.49.075.015/1505 0.7 W 24 V Bi-Pin T 1/T 1 >
1 / >
4 transparent blue 1.65.121.006/1607 1.65.121.906/0000 5.49.075.015/1607 >
Technical data see page 1 - 16 Accessories: Legend insert, square, without legend:5.70.638.000/2000Do not press in lens in disassembled condition.A notch on the lamp socket identifies the cathode side. Pushbuttons1 - 17
Stock items are markedby bold printed order numbers.
