RG 85 III short-stroke system

RG 85 III signal indicator, without lens Technical data

Dimensions Other specifications Length64 mm Mounting grid min.55 x 35 mmWidth 34 mm Ambient temp. operating min.-25 °C Ambient temp. operating max.+70 °C Storage temperature min.-40 °C Storage temperature max.+80 °C Resistance to constant environmentIEC 600 68-2-3 and 2-30Resistance at variableenvironmentIEC 600 68-2-14 and 2-33 Degree of protection rail mountingIP40 Degree of protection single mountingIP65 Flammability of materialsaccording to UL 94 HB Mechanical design Versionaccording to lens Mountingon U-rails or single mountingTerminals8-pin Micro-Match®female connectorIllumination5 LED for one colour Electrical characteristics Operating voltage LED24
+/-20% VInput current LEDsdepending on LED colour20 - 30 mA

4

Accessories RG 85 III signal indicator, without lens

Description Photo Order no. Page Cable, 8 wires, with socket connectors on both ends, length 2 m 5.03.772.262/0000 4 - 115 RG 85 III lens, square, for signal indicators 5.04.903.009/0000 4 - 114 RG 85 III lens, round, for signal indicators 5.04.903.010/0000 4 - 114 RG 85 III lens, triangular, for signal indicators 5.04.903.011/0000 4 - 115
RG85 III

4 - 106PCB Keyswitches

Stock items are markedby bold printed order numbers.
