RG 85 III short-stroke system

RG 85 III keylock switch

Ω Ω Contact resistance acc. to life max.3 Bouncing time max.10 ms Operating voltage LED24

Technical data

Dimensions Mounting grid min.55 x 35 mm Length64 mm Width 34 mm (35 mm with sealing) Mechanical design Versionround or squareMountingon U-rails or single mountingTerminals8-pin Micro-Match®female connectorContact systemcross contact Contact arrangement1 NO Contact materialsAu alloy Symbol illuminationnone Edge illumination4 LED pro colour Lockcylinder lock, lock type5201Key removal positionPos. 0 + 1 Mechanical characteristics
+/-20% VInput current LEDsper colour/LED row 9 - 16 mA Rotating angle1 x 90 ° Switching travel NO1 mm Electrical characteristics Rated voltage min.3 V Rated voltage max.42 V Rated current min.0.1 mA Rated current max.100 mARated power max.1 WContact resistance when new max.100 m Other specifications Ambient temp. operating min.-25 °C Ambient temp. operatingmax.+70 °CStorage temperature min.-40 °C Storage temperature max.+80 °C Resistance to constant environmentIEC 600 68-2-3 and 2-30 Resistance at variable environmentIEC 600 68-2-14 and 2-33 Operating life min.50000 Degree of protection rail mountingIP40 Degree of protectionsingle mountingIP65Flammability of materialsaccording to UL 94 HB

4

Accessories RG 85 III keylock switch

Description Photo Order no. Page RG 85 III lenses for keylock switches, round, stainless steel 5.04.914.200/2000 4 - 113 RG 85 III lenses for keylock switches, square, aluminum 5.04.915.201/2000 4 - 113
RG85 III

4 - 102PCB Keyswitches

Stock items are markedby bold printed order numbers.
