RG 85 III short-stroke system
RG 85 III keyswitch, round design, without lens
Contact arrangement Edge illumination Symbol illumination Version Order no. complete 1 NO 4 LED white round 3.99.400.111/2000 1 NO 4 LED red round 3.99.400.111/3000 1 NO 4 LED yellow round 3.99.400.111/4000 1 NO 4 LED green round 3.99.400.111/5000 1 NO 4 LED blue round 3.99.400.111/6000 1 NO 4 LED white, 4 LED blue round 3.99.400.111/7000 1 NO 4 LED green, 4 LED red round 3.99.400.111/8000 1 NO 4 LED white 2 LED yellow round 3.99.400.111/2400 1 NO 4 LED red 2 LED red round 3.99.400.111/3300 1 NO 4 LED yellow 2 LED green round 3.99.400.111/4500 1 NO 4 LED green 2 LED green round 3.99.400.111/5500 1 NO 4 LED blue 2 LED blue round 3.99.400.111/6600 >
4
1 NO 4 LED white, 4 LED blue 2 LED blue round 3.99.400.111/7600 1 NO 4 LED green, 4 LED red 2 LED red round 3.99.400.111/8300 1 NC + 1 NO 4 LED white round 3.99.400.131/2000 1 NC + 1 NO 4 LED red round 3.99.400.131/3000 1 NC + 1 NO 4 LED yellow round 3.99.400.131/4000 1 NC + 1 NO 4 LED green round 3.99.400.131/5000 1 NC + 1 NO 4 LED blue round 3.99.400.131/6000 1 NC + 1 NO 4 LED white, 4 LED blue round 3.99.400.131/7000 >
RG85 III 1 NC + 1 NO 4 LED green, 4 LED red round 3.99.400.131/8000 >
Technical data see page 4 - 98 Please order lenses (round shape) separately. PCB Keyswitches4 - 99
Stock items are markedby bold printed order numbers.
