RG 85 III short-stroke system
Ω Ω Contact resistance acc.
to life max.3 Bouncing time max.10 msOperating voltage LED24
RG 85 III keyswitch Technical data
Dimensions Length64 mm
Mounting grid min.55 x 35 mmWidth 34 mm Mechanical design Versionround or square
Mountingon U-rails or single mountingTerminals8-pin Micro-Match®female connectorContact systemsnap-action (1 NO ) or
industrial bridge contact (1 NC + 1 NO )Contact arrangementsee order blockContact materialsAg
Symbol illumination2 LED
Edge illumination4 LED pro colour
+/-20% VInput current LEDsper colour/LED row 9 - 16 mA Mechanical characteristics Electrical characteristics Operating force approx.3.5 N
Operating travel approx.1 mm
Switching travel NO1 mm
Switching travel NC0.6 mm Rated voltage min.3 V
Rated voltage max.50 V
Rated current min.0.1 mA
Rated current max.250 mARated power max.12.5 W
Contact resistance when
new max.100 m Other specifications Ambient temp. operating
min.-25 °C
Ambient temp. operating
max.+70 °C
Storage temperature min.-40 °C
Storage temperature max.+80 °C
Resistance to constant
environmentIEC 600 68-2-3 and 2-30Resistance at variableenvironmentIEC 600 68-2-14 and 2-33
Operating life min.1000000
Degree of protection
rail mountingIP40
Degree of protection
single mountingIP65
Flammability of materialsaccording to UL 94 HB
4
Accessories RG 85 III keyswitch
Description Photo Order no. Page Cable, 8 wires, with socket connectors on both ends,
length 1 m 5.03.772.261/0000 4 - 115 RG 85 III lenses for keyswitches, round, stainless steel 5.04.914.000/2000 4 - 110
RG85 III RG 85 III lenses for keyswitches, square, aluminum 5.04.915.100/2000 4 - 112
4 - 98PCB Keyswitches
Stock items are markedby bold printed order numbers.
