untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:2.20pt "Arial", sans-serif; } .font1 { font:5.00pt "Arial", sans-serif; } .font2 { font:6.00pt "Arial", sans-serif; } .font3 { font:8.00pt "Arial", sans-serif; } .font4 { font:11.00pt "Arial", sans-serif; } .font5 { font:13.00pt "Arial", sans-serif; } .font6 { font:31.00pt "Arial", sans-serif; } .font7 { font:6.00pt "Georgia", serif; } RACON short-travel keyswitches RACON 8, solder terminals for PCB, inward □ 8.40 3.50 i 3.57 6.35 ± 0.10 PCB footprint, view on component side 4.90±0.10(A) Terminals Contact arrangement Produkt code Packing Order no. solder terminal for PCB, inward 1 NO B1 in tubes ŕ 60 piece 1.14.100.502/0000 Technical data see page 4 - 6 For keycaps refer to chapter „RK 90", plungers see „RACON special accessories". RACON 8, SMD gullwing (Z) terminals typ. 11.00 3.57 4 □ 8.40 1 & 0/j0^ 4.90±0.10(A) _ I 7.60 max. ^ 12.00 min. PCB footprint, view on component side Terminals Contact arrangement Produkt code Packing Order no. SMD Gullwing (Z) terminals 1 NO C1 tape and reel ŕ 1000 piece 1.14.100.503/0000 Technical data see page 4 - 6 For keycaps refer to chapter „RK 90", plungers see „RACON special accessories". RACON PCB Keyswitches Stock items are marked by bold printed order numbers. 4 - 9
