RACON short-travel keyswitches
RACON 8, Typical system assembly with plunger under overlay
Solder terminal for PCB, outward Solder terminal for PCB, inward SMD gullwing (Z) terminal
L L A L A GH A GH GH 0.10 Variable Declaration Solder terminaloutward Solder terminal
inward SMD-terminal A Height of keyswitch A = 4.90
+/- 0.1 mm GH Overall height GH = A + L GH = A + L + 0.1 mm L Length of plunger L = GH - A L = GH - A - 0.1 mm
RACON 8, PCB hole pattern, smallest grid
Solder terminal for PCB, outward Solder terminal for PCB, inward SMD gullwing (Z) terminal view on component sideview on component sideview on component side
4
RACON RACON 8, SDM-terminal, tape and reel drawing Circuit diagram RACON 8
Switching symbols acc. to IEC 617 form X (twice interrupting)
PCB Keyswitches4 - 7
