table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:9.00pt "Arial", sans-serif; } .font2 { font:11.00pt "Arial", sans-serif; } .font3 { font:13.00pt "Arial", sans-serif; } .font4 { font:24.00pt "Arial", sans-serif; } RACON short-travel keyswitches General data RACON short-travel keyswitches with sealed contact system and distinct key click, excellent switching reliability. For use under an overlay or with RK 90 keycaps. Print and SMD versions available (suitable for automatic assembly). Content RACON 8 4 - 6 RACON 8, solder terminals for PCB, outward 4 - 8 RACON 8, solder terminals for PCB, inward 4 - 9 RACON 8, SMD gullwing (Z) terminals 4 - 9 RACON 12 4 - 10 RACON 12, solder terminals for PCB, outward 4 - 12 RACON 12, solder terminals for PCB, inward 4 - 13 RACON 12, SMD gullwing (Z) terminals 4 - 13 RACON 12 V with vertical adapter 4 - 14 RACON 12 V with vertical adapter 4 - 15 RACON 12 i 4 - 16 RACON 12 i, solder terminals for PCB 4 - 18 4 RACON RACON special accessories 4 - 20 Plunger for membrane data entry system 4 - 20 Square plunger for membrane data entry system 4 - 22 PCB Keyswitches 4 - 5
