HAFI RF short-travel keyswitches
RF 19 short-travel keyswitch
General data
Application notes:
RF 19 keys offer a large actuation area. When designing low-profile industrial keyboards with a grid of >= 23 mm, frame webs re­main free between the individual keys.
The overlay can be glued onto these frame webs; we recommend area embossing over the keys for the overlay.
Technical data
Rated power max. (ohmic load) Contact resistance when new max.
Contact resistance acc. to life m ax. Insulation resistance ESD strength (underneath overlay) Bouncing time max.
Other specifications
Ambient temp. operating min.
Ambient temp. operating max.
Storage temperature min. Storage temperature max. (product)
Storage temperature max. (in tube)
Resistance to constant environment
Resistance at variable environment
Operating life min. Soldering time max. Soldering temperature max.
Flammability of materials
General information
Colour of lens Recommended key grid
Dimensions
Length
Width
Overall height
Mechanical design
Mounting Terminals
Contact system Contact arrangement Contact materials Illumination LED colour LED type
M echanical characteristics
Operating force max. Operating travel Switching travel Robustness min.
see order block 23 mm
Au: 2 W, Ag: 12.5 W
100 m Q
3 Q 109 Q
15 kV 5 ms
4
19.05 mm 19.05 mm 9.7 mm
soldering into PCB contacts tin-plated, fix contact Ag plated snap-action contact 1 NO Au/Ag
spot-/fully illuminated see order block see order block
-25 °C
+70 °C -40 °C
+80 °C
+50 °C
according to IEC 600 68-2-3 and 2-30
according to IEC 600 68-2-14 and 2-33
1000000
2.5 sec.
250 °C
UL 94 HB
RF
2 ... 3 N 0.5 mm 0.5 mm
with through-plated PCB 100 N
Electrical characteristics
Rated voltage min. Rated voltage max. Rated current min. Rated current max.
Au: 0.02 V, Ag: 3 V Au: 42 V, Ag: 50 V Au: 0.01 mA, Ag: 0.1 mA Au: 100 mA, Ag: 250 mA
4 - 50
PCB Keyswitches
Stock items are marked by bold printed order numbers.
