RF short-travel keyswitches
RF 15 signal indicator Technical data
General information Colour of lenssee order block
Recommended key grid19.05 mm Dimensions Length15 mm
Width 15 mm
Overall height9.7 mm Mechanical design Mountingsoldering into PCBIlluminationfully illuminated 1 LEDLED coloursee order block
LED type2 mm Other specifications Ambient temp. operating
min.-25 °C
Ambient temp. operating
max.+70 °C
Storage temperature min.-40 °CStorage temperature max.
(product)+80 °CStorage temperature max.(in tube)+50 °C
Resistance to constant
environmentaccording to IEC 600 68-2-3 and 2-30Resistance at variable
environmentaccording to IEC 600 68-2-14 and 2-33Soldering time max.2.5 sec.
Soldering temperature
max.250 °CFlammability of materialsUL 94 HB
4
RF 4 - 46PCB Keyswitches
Stock items are markedby bold printed order numbers.
