PCB Keyswitches

Examples for ApplicationsStandards

RF 15

CE-Conformity

The products of the Chapter ”PCB Keyswitches” can – re-lating to the CE-conformity according to the Low-Voltage Directive 73/23/EWG – be divided into the following groups: All products with an operating voltage U
B > 50 V F. ex. Short-Travel Main Switch KN 19, for this product the Low-Voltage Directive 73/23/EWG applies. All products with an operating volltage U
B < 50 V F. ex. RACON, RF 15, RS 76, for these components no directive applies. RG 85 III System Single parts, accessories and illumination No directive applies for these products. EMC-Law Declarations of Conformity The components of this catalogue are within the meaning of the law concerning the electromagnetic conformity (= EMC-Law) ”basic components as, for ex., switches, signal lamps or like” and, therefore, do not fall within the scope of the EMC-Law. Declarations of conformity for all concerned products are available and can be delivered upon request. Please always state the exact order reference of the respective product. Marking The marking will be corresponding to the Low-Voltage Directive 73/23/EWG resp. the Directive ”CE-Marking 93/68/EWG” either on the packing or on the product itself or on the shipping documents.

4

RF 15 with RK 90 System

UL-approval

for

RACON

8/12, KN 19 and

Short-Travel Keyswitches

RF 15/19 The Short-Travel Main Switch KN 19 and data entry systems wich are built with Rafi short-travel switches according to our design proposals meet the requirements of the UL approbals for the American market.ULfile no. for KN 19:E 116362UL file no. for data entry systems:E 202520

4 - 4PCB Keyswitches
