RF short-travel keyswitches
Accessories RF 15 N short-travel keyswitch
Description Photo Order no. Page LED yellow, 3mm 1.90.690.103/0000 LED spacer for RF 15 N, 5 mm, spacing length 2.2 mm,
light grey, for use with overall height of 12.5 mm 5.30.109.010/0756 Extension plunger for RF 15 N, 10 mm, overall height
22.5 mm 5.46.011.028/0710 Extension plunger for RF 15 N, 15 mm, overall height
22.5 mm 5.46.017.028/0710
RF 15 N short-travel keyswitch, non-illuminated
Contact materials Illumination Recommended key grid Overall height Order no. Au external 3 mm LED possible ifheight 19.05 mm 6.2 mm 3.14.100.601/0000 Ag external 3 mm LED possible if
height 19.05 mm 6.2 mm 3.14.100.606/0000
Technical data see page 4 - 32 4
RF PCB Keyswitches4 - 35
Stock items are markedby bold printed order numbers.
