Digem DPM Catalogue table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:8.00pt "Arial", sans-serif; } .font1 { font:13.00pt "Arial", sans-serif; } .font2 { font:31.00pt "Arial", sans-serif; } .font3 { font:44.00pt "Arial", sans-serif; } .font4 { font:48.00pt "Tahoma", sans-serif; } PCB Keyswitches Versions Recommended Key grid Illumination Overall height Contacts Page Keyswitch Signal indicator RF 19 H (high profile) > 24 mm Fully illuminated 12.5 mm Gold or Silver 4 - 60 Main switch KN19 > 19.05 x 38.1 mm Non-illumi- nated Spot illuminated with 1 LED 9.7 mm Silver 4 - 75 RK 90 System > 12.50 mm Depending on the type of keyswitch used: - RACON (without plunger) - RF 15/RF 15 N - RF 19 - KN 19 4 - 79 RG 85 III System > 35/55 mm Edge-illuminated and symbol illumination Fully illuminated 14 mm Silver 4 - 95 Full-Travael Keyswitch RS 76 O > 19.05 mm Non- illumi- nated Fully/spot illuminated 15.5/15.9 mm (with key caps) RS 76 M: Gold RS 76 C: contactless 4 - 115 Keyswitches for Conductor Board 1 > 19.05 mm Non-illuminated 19.5 mm (without key) Gold 4 - 143 4 PCB Keyswitches 4 - 3
