RACON short-travel keyswitches

RACON 12 V with vertical adapter General data

The RACON 12 V version can be used, for example, for PC plug-in boards and for measurement and control engineeringapplications. The vertical mounting adapter (support element) absorbs the operating force so that the pressure on the soldered terminals is reduced. For this mounting arrangement, the keyswitch is provided with two horizontal terminals on one side.

Technical data

Dimensions Length14.5 mm Width 13.6 mm Overall height4.95 mm Mechanical characteristics Other specifications Operating force3.6 Ambient temp. operating min.-40 °C Ambient temp. operatingmax.+80 °C Storage temperature min.-50 °CStorage temperature max. (product)+85 °C Storage temperature max. (in tube)+85 °C Resistance to constant environmentaccording to IEC 600 68-2-3 and 2-30Resistance at variableenvironmentaccording to IEC 600 68-2-14 and 2-33Operating life at R Mechanical design

4

Mountingsoldering TerminalsPCB terminals Contact systemsnap-action contact Contact arrangement1 NO Contact materialsAu Illuminationno
RACON +-0.7 NSwitching travel0.61
+-0.1 Ω mm Insulation resistance10 Electrical characteristics
T = 23°C and test force = 1,5 x rated force1000000 Solderability / solder heat resistanceaccording to IEC 600 68-2-20Flammability of materialsUL 94 HB Packingin boxes à 100 piece Produkt codeF 1 Rated voltage min.0.02 VRated voltage max.42 VRated current min.0.01 mA Rated current max.100 mA Rated power max. (ohmic load)1 W Contact resistance when new max.100 m
9 Ω Bouncing time max.5 ms

4 - 14PCB Keyswitches
