RS 76 full-travel keyswitches

RS 76 C keyswitch, illuminated Technical data

General information Recommended key grid19.05 mm Mechanical design Contact functionsee order block Mountingsoldering Terminalssolder terminals, tin-platedContact systemcontactless with Hall-ICIlluminationwith LEDLED coloursee order block
PHL 3 µsOutput switching times (Q) bei 25°C, t
PLH 4 µsOutput switching times (Q) bei 25°C, t Electrical characteristics Mechanical characteristics Number of LEDsee order block Operating voltage DC4.75 ... 5.25 V Supply current max. at U
THL 1 µsOutput switching times (Q) bei 25°C, t Switching travel on1.5 - 2.8 mm Switching travel off0.8 ... 2.4 mm Operating force max.0.7 N Operating travel4 mm Robustness min.100 N
TLH 2 µs Other specifications = 2.5 x 10 Reliability of Hall-IC’s at 25°C
-7 h
-1 Ambient temp. operatingmin.0 °C Ambient temp. operating max.+70 °C Storage temperature min.-40 °C Storage temperature max. (product)+80 °C Storage temperature max. (rail)+50 °CResistance to constantenvironmentaccording to IEC 600 68-2-3 and 2-30Resistance at variable environmentaccording to IEC 600 68-2-14 and 2-33Operating life min.see order block Degree of protection IP40 Flammability of materialsUL 94 HB

4

IL = 0 V0.5 mASupply current max. at U
IH = 5 V5 mAInput voltage (F) at U
IL = 0 V0.4 VInput voltage (F) at U
IH = 2.4V5.25 VOutput load current (Q) max.16 mA Output residual current (Q) max.10 µA Output saturationvoltage (Q) max. bei 16 mA0.4 V ESD strength max.8 kV Output switching times (Q) bei 25°C, t

Accessories RS 76 C keyswitch, illuminated

Description Photo Order no. Page LED yellow, 3mm 1.90.690.103/0000 5 - 21
RS76 Cover for RS 76 IP40, 1-module, dark grey 5.04.520.174/0801 4 - 145

4 - 134PCB Keyswitches

Stock items are markedby bold printed order numbers.
