RS 76 full-travel keyswitches
RS 76 M keyswitch, non-illuminated
Contact function Illumination Contactarrangement Contact
materials Operating travel Operating force
max. Order no. complete momentary no 1 NO Au alloy 4 mm 0.9 N 3.13.002.502/0000 momentary no 1 NO Au alloy 4 mm 1.4 N 3.13.002.512/0000
Technical data see page 4 - 126 For accessories, refer to RS 76 special accessories.For keycaps, see keycaps for RS 76. RS 76 M keyswitch with diode, non-illuminated
Contact function Illumination Contact
arrangement Contact
materials Operating travel Operating force
max. Order no. complete momentary no 1 NO Au alloy 4 mm 0.9 N 3.13.005.001/0000
4
momentary no 1 NO Au alloy 4 mm 1.4 N 3.13.005.011/0000
Technical data see page 4 - 126 For accessories, refer to RS 76 special accessories.For keycaps, see keycaps for RS 76. RS76 PCB Keyswitches4 - 127
Stock items are markedby bold printed order numbers.
