RS 76 full-travel keyswitches

Specific Technical Data RS 76 C

Output pulse diagramDynamic characteristics Tw = 25 °C Tw = 50 °C Tw = 70 °C (max.) Turn-on delay time t
PHL 3 µs 7 µs 10 µs Turn-off delay time t
PHL 4 µs 5 µs 6 µs Fall/rise time t
PHL 2 µs 2,5 µs 3 µs t
PHL 1 µs 1,5 µs 2,5 µs

4

Static with Enable Input
RS76

PCB Keyswitches4 - 123
