RACON short-travel keyswitches
RACON 12, Typical system assembly with plunger under overlay
Solder terminal for PCB, outward Solder terminal for PCB, inward SMD gullwing (Z) terminal
L L L A A GH A GH GH 0.10 Variable Declaration Solder terminaloutward Solder terminal
inward SMD-terminal A Height of keyswitch A = 4.95
+/- 0.1 mm GH Overall height GH = A + L GH = A + L + 0.1 mm L Length of plunger L = GH - A L = GH - A - 0.1 mm
RACON 12, PCB hole pattern, smallest grid
Solder terminal for PCB, outward Solder terminal for PCB, inward SMD gullwing (Z) terminal
5.00 1.60 Ø 1.20 12.50 ± 0.10 Ø 1.20 5.00 5.00 10.00 ± 0.10 max11.30 RMmin=15.24 RMmin=12.50 min15.80 RMmin=12.50 RMmin=12.50 RMmin=16.50 RMmin=12.50 view on component sideview on component sideview on component side
4
RACON 12, SMD-terminal, tape and reel drawing
RACON Circuit Diagram RACON 12
Switching symbols acc. to IEC 617 form X (twice interrupting)
PCB Keyswitches4 - 11
