untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:8.00pt "Arial", sans-serif; } .font3 { font:9.00pt "Arial", sans-serif; } .font4 { font:11.00pt "Arial", sans-serif; } .font5 { font:13.00pt "Arial", sans-serif; } .font6 { font:27.00pt "Arial", sans-serif; } .font7 { font:68.00pt "Arial", sans-serif; } Luminous éléments Rated voltage Rated current Rated power Diameter max. Length max. Medium operating life AC Order no. complete Accessory lamp extractor 220 AC (red) V 0.0015 -0.0018 A 10 mm 28 mm 1.90.560.102/0000 1.90.900.007/0000 220 AC (green) V 0.0015 -0.0018 A 10 mm 28 mm 1.90.560.104/0000 1.90.900.007/0000 Ratings and operating life spécifications generally refer to the lower rated voltage value. Operating life spécifications of lamps refer to AC operation. With DC operation, these are reduced by about 40%. Filament amps, BA 15c base, DIN 49850 B Rated voltage Rated current Rated power Diameter max. Length max. Medium operating life AC Order no. complete Accessory lamp extractor 12 - 15 V 0.12 A 2 W 15.2/ 12.5 mm 31 mm 1000 h 1.90.070.003/0000 1.90.900.008/0000 24 - 30 V 0.08 A 2 W 15.2/ 12.5 mm 31 mm 1000 h 1.90.070.004/0000 1.90.900.008/0000 Ratings and operating life specifications generally refer to the lower rated voltage value. Operating life specifications of lamps refer to AC operation. With DC operation, these are reduced by about 40%. 5 Lamps Accessories Stock items are marked by bold printed order numbers. 5 - 9
