Luminous elements

Filament lamps, Bi-Pin T 1 base

Rated voltage Rated current Rated power Diametermax. Length max. Medium operating life AC Order no. complete Accessory lamp extractor

24 - 28 V 0.016 A 0.4 - 0.56 W 5000 h 1.90.180.473/0000 1.90.900.001/0000

Ratings and operating life specifications generally refer to the lower rated voltage value. Operating life specifications of lamps refer toAC operation. With DC operation, these are reduced by about 40%.

Filament lamps, Bi-Pin T

/

base

Rated voltage Rated current Rated power Diameter max. Length max. Medium operating life AC Order no. complete Accessory lamp extractor

12 V 0.06 A 0.72 W 4.3 mm 10.5 mm 10000 h 1.90.180.474/0000 1.90.900.002/0000 28 V 0.03 A 0.84 W 4.3 mm 10.5 mm 5000 h 1.90.180.475/0000 1.90.900.002/0000

5

Lamps

Accessories5 - 5

Stock items are markedby bold printed order numbers.
