Components and Systems for Elevators and Building Automation >

RAFI supplies high quality electromechanical components for elevators and building automation. > RAFI short travel keyswitches MICON, RACON or RF 15/19 for use in input systems under overlay or keycaps. Short travel keyswitch RF 19 with 1 normally closed and 1 normally open contact, e.g. for Alarm Button. Pushbuttons, keyswitches and displays with border and symbol illumination, round or square. Connection via 8-pin Micro-Match socket connector. Modular mounting system with rails or individual fi xing. > Keycaps with 3D surface in accordance with EN 81-70 RAFI short travel keyswitchesExample...

RAFIX 16, 22 FS and 22 QR, robust control units for various applications. > Control unit family RAFIX 22 FS, installation depth of only 9.2 mm possibleExample application: inspection control unit with RAFIX 22 QR RAFI signal lampsSignal lamp with LED Authorisation keyswitchKeyswitch LUMOTAST 75 Signal lamps and luminous fi elds in vari-ous colours and shapes with integrated LED or with lamp fi ttings. > Various functions, shapes and connection versions, e.g. authorisation keyswitch with different switch positions per key. >

CUSTOMISED COMPONENTS especially for your requirements > Sometimes, for reasons of design or function, our components cannot fully meet the requirements of our customers. As we design and produce our products in our own factories, we can implement challenging solutions based on our stan- dard components. Examples of customised pushbuttons size="-1">

CUSTOMISED DATA INPUT SYSTEMS complete and ready for plug in > Fully customised data input systems with integrated interfaces. Ready for connec- tion with your controller. Standard bus systems such as CAN, CANopen, Ether- net etc. supported. Numeric keypad with stainless steel keys Numeric keypad for multi-digit fl oor inputCall station Hall lantern Car operation panel size="-2">

DIN ISO 9001:2000 (DQS) ISO/TS 16949:2002 (DQS) Contact technology Plastic injection moulding Sheet metal machining Silk screen printing Pad printing From manual to fully automatic assembly > Basic development Material testing > Circuit development Component selection PCB design Software development > Manual and automatic mounting of SMD and THT components Soldering (reflow, wave, vapour phase and selective soldering) Automatic functional tests (ICT, AOI) Solutions for elevators and building automation have always been a special challenge for development, production and quality assurance. We...
