wtoRAE Lite station

Specifications

Detector Specifications*

AutoRAE Lite includes:

• AutoRAE Lite as specified

• USB cable for PC set up

• 12 volt power supply

• Demand low regulator

• SD memory card minimum 512Mb

• Quick start guide

• Inlet filter

• CD including

- Operation manual

- Drivers

- Utility software


	Certifications	CE
	Sensor	Light and sound sensors
	Data Storage	Excel format daily files for: 1. Bump test 2. Calibrations 3. Alarms Tamper proof
	Bump Test Time	12 sec
	Bump Test Gas Usage	70 cm3
	Calibration Time	2 min
	Calibration Gas Usage	300 cm3
	Pneumatic System	Demand flow regulator Built-in pump "No gas low" alarm
	Power Supply	12 VDC or Battery pack
	Battery Runtime	700 bump tests on 4 C size battery
	Operating Temperature	14° F to +122° F (-10° C to +50° C)
	Humidity	10% to 90% RH non-condensing
	Dimensions	15" L x 12.5" W x 6.5" H (38cm x 32cm x 17cm)
	Weight	9 lbs (4.1 kg)

Ordering Information

* Specifications are subject to change

Toll-Free: 877-723-2878

www.raesystems.com

USA/Canada 1-877-723-2878

Europe/Russia +45 8652 5155

Middle East/Australia +971 4 3639 427

China +86 10 58858788

Asia +852 2669 0828

RAE Systems Inc.

3775 North First Street San Jose, CA 95134 USA raesales@raesystems.com

DS-1006-01
