Coaxial Couplers - Radiall - #2

Text version of the page

table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:5.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:8.00pt "Arial", sans-serif; } .font3 { font:11.00pt "Arial", sans-serif; } .font4 { font:12.00pt "Arial", sans-serif; } .font5 { font:13.00pt "Arial", sans-serif; } .font6 { font:22.00pt "Arial", sans-serif; } COAXIAL COUPLERS INDEX 1 - MANUFACTURERA CODE NUMBERS.......................................... 3 2 - FACILITES AND CUSTOMERS............................................... 4 3 - GENERAL SPECIFICATIONS.................................................. 6 3.1 Environmenîal characteristics 3.2 Mechanical characteristics, materials and finishes 3.3 Manufacturing and quality assurance 4 - SELECTION GUIDE......................................................... 8 5 - CATALOG TERMS AND CHARACTERISTICS OF TECHNICAL DATA ............... 10 6-PRODUCTS.............................................................. 14 6.1 3 dB 90° hybrid SMA coaxial couplers 6.2 Fiat response unidirectional coaxial couplers 6.3, 3 dB 90° hybrid high power coaxial couplers 6.4 Unidirectional high power coaxial couplers 7 - SPECIAL COUPLER DESIGNS AND CONFIGURATIONS.......................... 23 1 - MANUFACTURERS CODE NUMBERS RADIALL, Military supply code manufacturer F0503 and F6507, is a qualified supplier of coaxial couplers under military specificaîions.as well as other microwave components, to various governmental agencies. Radiail Quality Assurance is fuily approved by NATO (AQAP4). The following is a partial listing of national stock numbers which RADIALL has provided to the French Ministry of Defence. MSCM RADIALL Part number NSN F657 R 432 134 5985 14 3137794 R 432 171 5985 14 309 9409 R 432 271 5985 14 309 9410 R 432 274 5985 14 324 2002 R 432 275 5985 14 367 8714 R 432 371 5985 14 300 2509 R 432 432 5985 14 327 7287 R 432 433 5985 14 315 5751 R 432 464 5985 14 356 8349 R 432 472 5985 14 337 0311 R 432 531 5985 14 350 6498 R 432 533 5985 14 374 8394 R 432 534 5985 14 353 7761 R 432 631 5985 14 322 4824 R 432 632 5985 14 331 9482 R 432 634 598514 318 2466 R 432 763 5985 14 297 5020 R 432 951 5985 14 380 7448 R 432 464 5985 14 386 8557 R 432 523 5985 14 376 0750 R 432 611 5985 14 421 9734 R 432 613 5985 14 418 7019 R 432 723 5985 14 362 3159 RADIALL The Quality Connection ® 3
