COAXIAL COUPLERS
6.4 DIRECTIONAL HIGH POWER COAXIAL COUPLERS
RF CHARACTERISTICS
RADIALL PART NUMBER
FREQUENCY RANGE (GHz)
COUPLING (dB)
FREQUENCY SENSITIVITY ± (dB)
INSERTION LOSS (dB)
DIRECTIVY (dB)
VSWR
SNPUT POWER AVE RAGE PEAK (W) (KW) (1) (2)
FIGURE
R 432 957
6-18
30 ± 1
1
0.5
15
1.30/1.40
100
2.5
1
R 432 959
6-18
40 ± 1
1
0.5
15
1.30/1.40
100
2.5
1
R 433 955
2-8
30 ± 1
0.5
0.25
16
1.30/1.40
300
2.5
2
R 433 956
2-8
40 ± 1
0.5
0.25
16
1.30/1.40
300
2.5
2
R 433 967
6-18
30 ± 1
0.7
0.5
12/10 (3)
1.40/1.60
400
3
3
R 433 969
6-18
40 ± 1
0.7
0.5
12/10 (3)
1.40/1.60
400
3
3
Notes : (1) at 25°C
(2) at 25°C Ous-duty cycle 1%o)
(3) 6-15GHz/15-18GHz
(4) main line/coupled line
MECHANICAL CHARACTERISTICS
CONSTRUCTION
SPLASHPROOF
RF CONNECTORS
SMA PER MIL C 39012
ENVIRONMENTAL CHARACTERISTICS (In accordance with MIL STD 202)
OPERATING TEMPERATURE RANGE
-40/+85°C
STORAGE TEMPERATURE RANGE
-55/+100°C
VIBRATION (MIL STD 202)
METHOD 204 cond D (10-200Û/20G)
SHOCK (MIL STD 202)
METHOD 213 cond C (100G/6mS)
RADIALL
The Qunlity Connection
®
20
