TECHNICAL INFORMATION
III LIST OF APPLICABLE DOCUMENTS :
List of related standards covering the general mechanical and climatic tests applicable to the devices described in this
catalog.
D AIR 7304
D CEI 169.13
D DIN 47295
D GAM EG 13
D NFC 207xx
D NFC 93561
D NFC 93562
D NFC 93563
D NFC 93564
D NFC 93566
D NFC 96315
D MIL C 39012
D MIL A 3933
D MIL E 5400
D MIL STD 202
IV ENVIRONMENTAL CHARACTERISTICS :
Coaxial
Attenuators
5
Operating temperature
range
Storage temperature
range
All the models -- 55°C, + 125°C -- 55°C, + 125°C
V MATERIALS AND FINISHES :
Body Passivated Stainless Steel or Brass Nickel plated
Contact Beryllium Copper Gold plated (CuBe2)
Heatsink Aluminium black anodized
Insulator P T F E or ULTEM 1000
Resistor circuits Tantalium Nitride Thin film on ceramic substrates
Ruthenium Oxide Thick film on ceramic substrates
Tantalium Nitride Thin film on Aluminium Nitride substrates
