6
MODEL MK6
TECHNICAL SPECIFICATIONS
Press-fit precision metal bellows coup
Properties:
■ electrically insulated
■ self-adjusting
■ no wear
■ easy mounting and dismounting
■ blacklash-free and torsionally rigid
■ low moment of inertia
■ compensates for 3-axis of misalignment
Bellows made of highly flexible high-grade stain­less steel, clamping hub aluminium. Expanding hub and cone (steel)
On one side an expanding shaft with tapered clamping element. On one side a clamping hub. Backlash-free, blind mate press-fit connection (glass-fiber reinforced plastic)
-30° to +120° C (3,6 F to 270 F),
Up to 10,000 rpm, in excess of 10,000 rpm available with balanced version
These couplings have an infinite life, and are maintenance-free if the technical ratings are not exceeded.
On the hub/shaft connection 0.01 to 0.05 mm.
I ISO 4762
E ISO 4762
fl\
Material: Design:
Temperature range:
Speed: Service life:
Fit tolerance:
A*" (Press-fit length)
! Standard S Option M single multi
position position
Pretensioning i
MK6/20 / 28 / 12 /12 / XX
Model
Series/Nm
Overall length (mm)
Shaft 0 D1 f7
Bore 0 D2 H7
non standard e.g. Option M
Model mk 6
Rated torque
(Nm)
0.5
1.5
2
4.5
10
Length without pretensioning (mm)
21
24
27
27
32
28
34
38
38
46
45
55
Outer diameter
(mm)
B
15
19
25
32
40
Shaft length
(mm)
C,
10
12
12
15
20
Standard shaft 0 f7
(mm)
8
10
12
14
16
Fit length
(mm)
12
14
16
20
21.5
Special bores from 0 to 0 H7 (mm)
3-6.35
3-8
3-12.7
5-16
5-20
Standard bore H7
(mm)
CD
6
6/10
10
10
ISO 4762 screws
M2
M2.5
M3
M4
M4
Tightening torque of the assembly screws
(Nm)
0.43
0.85
2.3
4
4.5
Distance between centers
(mm)
4.5
6
CO
10
15
Distance
(mm)
3
3.5
4
5
5
Pretensioning approx.
(mm)
H
0.4
0.5
0.5
0.7
1
ISO 4762 screws
M3
M4
M4
M5
M6
Tightening torque of the assembly screws
(Nm)
1.5
3
4
6.5
11
Axial recovery force
(N)
5
3
2
4
3
3
4
3
15
10
25
30
Mass moment of inertia
(gcm2)
Jges
3.0
3.2
3.5
9.0
10
28
30
33
110
120
220
230
Torsional stiffness
(Nm/rad)
CT
280
210
170
750
700
1200
1300
1200
7000
5000
9050
8800
lateral fJH№№
(mm)
Max.
0.15
0.2
0.25
0.15
0.2
0.15
0.2
0.25
0.2
0.25
0.2
0.3
angular -[JHffit^
(degrees)
values
1
1.5
2
1.5
1.5
1.5
1.5
2
1.5
2
1.5
2
www.rwcouplings.com
R+W
9
