Microsoft Word - deltaflow_p_Portable English geändert.doc table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.50pt "Arial", sans-serif; } .font1 { font:9.50pt "Arial", sans-serif; } .font2 { font:12.00pt "Arial", sans-serif; } .font3 { font:11.00pt "Times New Roman", serif; } .font4 { font:12.00pt "Times New Roman", serif; } .font5 { font:17.00pt "Times New Roman", serif; } m SPECIFICATIONS Power Source: 220V, 440V/1 Phase Knife plate size range: 7/8" to 1-7/8" (25 - 50mm) 1-7/8 to 3-5/8" (50-95mm) 3-5/8" to 5" (95 - 130mm) Production Rate: Up to 150 PPM Bottle Diameter Range: 7/8" - 5"(25 - 130mm) Dia. > 5" call for quote Label Length Range: 1" -12" (25 - 305mm) Label Thickness Range: .00137"- .00314 (.035 - .08mm) Material: PVC/PET/OPS Shrink Tunnel Capacity: Consult factory Machine Dimensions: 34" W x 32" L x 78" H (860 x 810 x2000mm) FEATURES • SL-100 is capable of speeds from 100450 PPM, dépendent on container and label. • Innovative cutting mechanism employs standard disposable knives. • Ail stainless steel construction for the harshest environments. • Microprocessor control with user-friendly operator interface provides on-board production information and troubleshooting instructions. Quick change knife plate. Sleeve advance driven by stepping motor. Pneumatically operated knife plate. Label insertion System allows use of 35 micron material. • 3-color stack lamp. Alerts operator of machine condition. • Accommodâtes core size of 3"-10." CONTAINER TYPES Filled or empty/ Plastic or glass. Oval, round, flat-side or complex shapes. TAMPER EVIDENT BAND OVERALL BOTTLE FULL E LABELING LABELING LABELING SYSTEMS 7670 Jenther Drive. Mentor, Ohio 44060 Phone: 440.602.4700 Fax: 440.602.4701 TollFree: 800.321.8509 email: labeling@quadrel.com www.quadrel.com
