Force [kN]Distance [mm]

UFM - 20081 MANUFACTURING VALUE FOR MONEY, INTELLIGENT ASSEMBLY

PRESSING
bearings in at a distance without stops with monitoring of the pressing force. The universal electro mechanical assembly unit was develo-ped for demanding applications in the Heavy Industry Envi- ronment. Its use in automated assembly lines or in manual work-places offers the user countless advantages:– Extremely robust set-up, suitable for long periods of use – High speeds and high acceleration for fast cycles and short cycle times – Integrated force distance monitoring for optimum Quality Assurance– Low repair and maintenance work reduces shutdown times and costs– High functionalities due to transparent technology, thus requiring less training– Fast setting-up, also for small and medium production runs– Low noise development and clean use– Low radial play– Flexible and precise for a broad area of applications JOINTING
Force [kN]Distance [mm] rotor shafts with exact press in position. RIVETS
Force [kN]Distance [mm] with programmed pressing force. MOLDING/SHAPING
detection of the part height and relative shaping distance. repeat accuracy of the programmed force of ± 1%. Force [kN]Distance [mm]

APPLICATION EXAMPLES

The product was incidentally at the time of its introduction to the market in the late 80’s the first innovative manufac- turing unit with an NC-control integrated in the PC and an operator interface in MS-Windows. In the meantime it has become a highly functional unit meeting all requirements.Numerous reliable Electro Mechanical Assembly Units are in heavy industrial use all over the world. The Application Areas for the assembly units are diverse:– Pressing rotors into sheet metal packages– Pressing rubber dampers into metal bearings – Setting and testing springs – Molding rings to exactly 0.001 mm – Pressing winding packages into the housing – Use in riveting technology as well as in butt-welding plants– Crimping of Electrodes – Pressing bearing jewels into clockwork mechanism – Assembly of injectors, bending of valvesClose relations with our well-known customers in the automotive and electrical industry lead to continuous improvement and extension of the functionalities and performance of our products. As an innovative company we are in constant search for new opportunities of use for our customers. SPRING TESTING
Force [kN]Distance [mm] Measuring and reporting the spring resistance in certain positions and with monitored linearity. STAMPING
with cutting force monitoring. Stamping with continuous stampforce monitoring: Thick- ness of the sheet and cutting state is monitored constantly. Force [kN]Distance [mm] PRECISE THROUGHPUT
Force [kN]Distance [mm] thanks to very exact tolerance ram positioning. BENDING
Force [kN]Distance [mm] as a standard operation for prototypes and series.
