Rectangular Section Priorclave Datasheet - Priorclave - #1

Technical Datasheet \\2k3server\Users\PRichardson\Priorclave\TechSpecSheets\RSC Priorclaves.doc

• 230, 350, 450 and 700 Litre Capacities

• Large rectangular chamber within a compact frame

• Two or three (450 & 700L Models) handwheel closure system with patented Priorclave safety mechanism

• Electrically Heated or Direct steam heated models available

• Steam generated within the chamber (electrically heated models)

• Insurance approved, stainless steel grade 316L chamber manufactured under an ISO 9000 regime.

• Conforms to BS2646-1993, Pressure Equipment Regulations PD5500:2000 Cat.3, European PED 97/23/EC, EMC Compliance tested and CE marked, for BS EN61010-2-41, Low Voltage Directives, amongst others

• Supplied with two full width stainless steel shelves.

• Rapid cooling system as standard.

Operation up to 138°C - 2.4. The TACTROL microprocessor control system has staged illumination giving digital readouts of cycle status and the simple to set control panel features adjustable temperature and time that can be viewed simultaneously. Ideally suited for use in a wide range of applications:

Sterilisation - media preparation, liquids and diluent, waste, glassware, instruments, apparatus, health care

Non-sterilisation - food processing, plastics, accelerated curing, construction.

Extensively used within many industries, including: food, drink, dairy, pharmaceutical, agricultural, education, healthcare, research establishments and industry.

The pressure vessel is insurance approved.

Safety features include: special safety handnut mechanism, which cracks the gasket seal allowing any residual pressure to safely escape. A

07/01/2002

thermal cooling lock, preventing the door from being opened until the contents have cooled to a safe temperature and a pressure interlock are

*where applicable to model chosen Connection RSC230 RSC350

also fitted. The unit also features a low water level sensor, that prevents boil-dry conditions and a safety blow down valve affords further protection.

400V 21kW 30A 3 Phase

400V 21kW 30A 3 Phase

400V 32.5kW 45A 3 Phase

BSP.

1300mm

400V 42kW 60A 3 Phase

Dry Steam reduced to 40psi. 1/"

1300mm 1300mm

28mm (1" BSP)

1395mm 1395mm

15mm (/" BSP)

400mm 400mm

15mm (1" BSP)

820mm 820mm

960x2210x 1635mm

The single vent outlet pipe can be directed to a nearby drain. For make safe processing the discharge should be directed to a sealed discharge system; the system should lead by direct connection to a building drain or catchment tank.

1550mm 400mm

820mm

1055x2305x 1790mm

1550mm 400mm

820mm

1055x2765x 1790mm

Dimensions are approximate only
