Compact 60 - 60L Benchtop Priorclave Datasheet - Priorclave - #1

Technical Specification Sheet CLS/C60/Bench 22/10/2002

Compact 60 Benchtop Priorclave fe^

Operation up to 138°C - 2.4 Bar. The TACTROL 2 microprocessor control system has staged illumination giving digital readouts of cycle status and the simple to set control panel features adjustable temperature and time that can be viewed simultaneously. Ideally suited for use in a wide range of applications:

Sterilisation - media preparation, liquids and diluent, waste, glassware, instruments, apparatus, health care.

Non-sterilisation - food processing, plastics, accelerated curing, construction.

Extensively used within many industries, including: food, drink, dairy, pharmaceutical, agricultural, education, healthcare, research establishments and industry.

The pressure vessel carries a 10 year warranty and is Insurance approved. The pressure door features: protective heat cover, thermal cooling lock, pressure lock, special door gate mechanism which cracks the

gasket seal allowing any residual pressure to safely escape. The unit also features a low water level sensor, that prevents boil-dry conditions and a safety blow down valve affords further protection.

The unit requires a 240V, 50Hz, 13-amp power supply. Should more heater power be required then a single phase, wall mounted isolator is required. The single vent outlet pipe can be directed to a nearby drain. For make safe processing the discharge should be directed to a sealed discharge system; the system should lead by direct connection to a building drain or catchment tank. Formore specific advice about yourparticular installation requirements please contact our Technical Department.

To allow room for autoclave doors to open and for connection to services, please note the following dimensions: Front Loaders Plan View

Loading Format: Front

Capacity (appx.): 60 litres

Maximum Temp: 136°C

Water Capacity: 3litres
