Powerware Product Catalog
40Pages

{{requestButtons}}

Catalog excerpts

Powerware Product Catalog - 4

Typical applications Standalone PC Home equipment Product highlights Available also with Schuko outlets Equipped with Modem/DSL surge line protector All you need included in the box Technology: Rating: Series 3 (offline) 350-500 VA Voltage: 230 Vac Backup time: 3 min with full load > In a perfect world, your incoming utility power would be smooth, steady, and completely reliable. In the real world, however, public power is plagued with sags, surges, and outages. A typical power customer experiences these events daily, and several complete outages a year. With Powerware 3105 you can continue...

Open the catalog to page 4
Powerware Product Catalog - 6

Typical applications SOHO applications Office computers and workstations Product highlights Series 5 UPS offering voltage regulation Silent UPS due to no fans Shutdown software, USB cable and two load cables included Technology: Rating: Series 5 (Line-interactive) 500-1000 VA Voltage: 230 Vac Backup time: 3-5 min with full load > In SOHO environment a crucial part of the work can be saved on single computers. Designed to meet todayΒs cost effective needs of power protection in SOHO environment, Powerware 5110 offers all features needed for office computer and workstation protection....

Open the catalog to page 6
Powerware Product Catalog - 8

Typical applications: Small office servers Small storage equipment Product highlights: Small size Software suite, signal cable & USB cable bundled Advanced Battery Management (ABM Technology: Series 5 (line interactive) Rating: 500-1400 VA Voltage: 220-240 Vac Backup time: Typical 5 min at full load Model: Cabinet Designed to offer cost effective power protection for small office servers, Powerware 5115 protects your equipment against five of the nine most common power problems that can harm your equipment or result in corrupted data.In offices a crucial part of the work is stored on...

Open the catalog to page 8
Powerware Product Catalog - 10

Typical applications: Product highlights: Small RM servers RM network devices Small storage equipment Only 1 U high Software suite bundled Advanced Battery Management (ABM > Technology: Series 5 (line interactive) Rating: 500-1500 VA Voltage: 220-240 Vac Backup time: Typical 5 min at full load Model: Rackmount The Powerware 5115 RM offers a cost effective solution needed for effective network protection and protects against five of the nine basic power problems that could harm your equipment or result in corrupted data.The Powerware 5115 RMΒs design provides high power density, only...

Open the catalog to page 10
Powerware Product Catalog - 12

Technology: Series 5 (line interactive) Rating: 1000-2200 VA Voltage: 200-240 Vac Backup time: Model: Cabinet Typical 5 min (extendable up to one hour) Typical applications: Product highlights: Small network servers Small storage equipment Network devices Extended backup time Connectivity options Software suite bundled Advanced Battery Management (ABM Designed to ensure clean power and reliable operation for all kinds of IT devices in network systems, Powerware 5125 protects your equipment against five of the nine most common power problems that can harm your equipment or result in...

Open the catalog to page 12
Powerware Product Catalog - 13

POWERWARE 5125 specifications tableRating 1000 VA 1500 VA 2200 VA Part number 05146630-5591 05146633-5591 05146637-5591Capacity (VA/Watts) 1000/700 1500/1050 2200/1600Dimensions WxHxD (mm) 162x250x401 162x250x467 205x250x493 Weight (kg)1623 31Input connection IEC320/10A IEC320/10A IEC320/10AOutput connection 6xIEC320/10A 6xIEC320/10A 9xIEC320/10ATypical runtime at 20C full load half load 5 min 15 min 6 min 20 min 6 min 20 min Operational Nominal input voltage (VAC) 220/230/240 VacInput voltage range 166 Ж 276 Vac (+20/-30% of nominal)Operating frequency 50/60 Hz auto sensingInput power...

Open the catalog to page 13
Powerware Product Catalog - 14

Typical applications: High density RM applicability Product highlights: Only 2U (1000-3000 VA), 3U (6000 VA) Extended runtimes PF 0.9 enables protection of more equipment Connectivity options Advanced Battery Management (ABM > Technology: Series 5 (line interactive) Rating: 1000-6000 VA Voltage: 220-240 Vac Backup time: Typical 5 min (extendable up to one hour) Model: Rackmount Designed to ensure clean power and reliable operation of all kinds of rack mounted IT devices in the network system, Powerware 5125 RM protects your equipment against five of the nine most common power problems that...

Open the catalog to page 14
Powerware Product Catalog - 18

Typical applications: Critical servers in rack configuration Telecom rack applications Product highlights: Only 2U (1000-3000 VA), 5U (5000-6000 VA) height conserves valuable rack spaceDouble conversion online technology Extended runtimes Connectivity options Advanced Battery Management (ABM Technology: Series 9 (double conversion) Rating: 1000-6000 VA Voltage: 230 Vac Backup time: Typical 5-13 min (extendable up to several hours) Model: Rackmount Designed for flexibility to meet the requirements of critical rack mounted equipment protection, the 9125 RM offers protection of all nine most...

Open the catalog to page 18
Powerware Product Catalog - 20

Typical applications Network rooms Enterprice class IT equipment Product highlights: Up to 10kVA in only 6U of rack space Optional 3U Extended Battery Modules Software Suite bundledAdvanced Battery Management (ABM > Technology: Series 9 (double conversion) Power Rating: 7,5-10 kVA at 0.8 p.f. Voltage: 230 V 50/60 Hz Backup time: Typical 5 min (extendable) Powerware 9140 delivers de-centralized power protection and power management for medium- and high- density rack environments and superior power management for expanding loads in shrinking spaces. Providing increased power density and power...

Open the catalog to page 20
Powerware Product Catalog - 23

Operational Nominal input voltage (Vac)S models: 220/230/240 Vac single phase;N models: 220/380, 230/400, 240/415 Vac three phaseInput voltage range 20% from nominal at 100% load, - 50%, +20% from nominal at 50% loadOperating frequency50/60 Hz (45 to 65 Hz)Input power factor0,99 Input current distortion2-5% THD in nominal load conditionNominal output voltage220/230/240 VAC single phaseOutput voltage regulationѱ2% static;5% dynamic at 100% load change, < 1 ms response timeOverload capacity150% for 1 min / 125% for 10 min / 110% for 60 min (mains available)150% for 5 sec (on battery)Permitted...

Open the catalog to page 23
Powerware Product Catalog - 25

Operational Nominal input voltage (Vac)220/380, 230/400, 240/415 Vac three phaseInput voltage range20% from nominal at 100% load, -50%, +20% from nominal at 50% loadOperating frequency50/60 Hz (45 to 65 Hz)Input power factor0,99Input current distortion2-5% THD in nominal load conditionNominal output voltage220/380, 230/400, 240/415 VacOutput voltage regulationѱ2% static;5% dynamic at 100% load change, < 1 ms response timeOverload capacity150% for 1 min / 125% for 10 min / 110% for 60 min (mains available) 150% for 5 sec (on battery)Permitted load power factors0,7 lag і 0,8...

Open the catalog to page 25
